| Motor power | 350W electronically controlled brushless DC motor (waterproof)(OEM) |
| Controller | 20A/9 tubes(OEM) |
| Speed | 30km/h(OEM) |
| Three mode speeds | Low speed (climbing)/Medium speed (city)/High speed (speed)/Reverse |
| Range | 40km-60km/Charge(OEM) |
| Angle of climb | 15 ° |
| Brake system | Front disc brake and rear drum brake/Front and rear disc brake/CBS brake(OEM) |
| Seat height | 740mm |
| Vehicle size | 1380*630*920mm |
| Front and rear wheelbases | 1430mm |
| Vehicle Weight(Without battery) | 64kg |
| Load limiting | 200kg |
| Tyre | Front 12*2.5 rear14*2.125 vacuum tire |
| Light | LED |
| Voltage | 48 volts |
| Battery | Lead acid battery or Lithium battery |
| Alarm function | Central lock with burglar alarm, keyless start, find my electric car feature |
| Charger specification | 48V /3A or 6A/ automatic power off(OEM) |
| Charging time | 3 to 5 hours /6 to 8 hours |
| Front and rear shock absorption | Front - True hydraulic telescopic,Rear - True hydraulic dual shock absorbers and dual tube technology |
| Minimum ground clearance | 140mm |
| Baking paint | Light curing painting |
| Brake handle | Aluminium alloy |
| Peculiarity | USB charging, one click rescue button, reverse gear |
| 40HQ（CKD） | 150pcs |
| 40HQ（SKD） | 90pcs |
